Smooth, Quiet Operation

High Wind Rated Roller Door

Precision Springing

Consistent Balance

Bottom Weatherseal

Wide range of colours

Economical

Curtain Qualities

Continuous brake pressed steel curtain

Manufactured from 0.5mm gauge, flexible steel curtain, pressed to a horizontal ribbed profile, sliding between vertical guides

Deep rigid channel grooves

Aluminium bottom rail with weatherseal

Sizes up to 5100mm high x 5500mm wide or up to 3300mm high and 5500mm wide for non-windlocked configurations

Benefits

Prevents penetration of moisture and dust, thereby minimising the chance of corrosion

Strong, while providing an attractive appearance

Added protection against dirt, leaves and weather

Smooth, Quiet & Easy Operation

Nylofelt® is used to minimise friction at the working surface.

Continuous smooth, quiet operation is an ongoing benefit of this product, without so much as a touch of lubricant.

Secure Locking

Waist high slide bolt locking is located internally and supplied on the left hand side as standard

Waist high internal slide bolt located on right hand side or both sides

No bending required to unlock doors

Ensured security

Optional centre lift lock with external key and internal knob operation, or internal and/or external bottom rail slide bolt locking

Easy Opening

The gearing assembly is mounted inside the door roll to minimise side clearance requirements and with its no maintenance, low friction characteristics, provides low operating effort to open and close very large doors. Features include:Doors up to 2400mm high can be operated by hand without the need of chain wheel equipmentDoors between 2400mm and 3000mm use efficient direct chain driveDoors over 3000mm high use efficient, compact, planetary reduction gearingQuiet and durable nylon gearingEase of single handed operationGearing components require no lubrication due to materials used in manufacturingBalanced loading and withstands very high overload forces without ill effects

Colours

B&D Series 2 Light Industrial Roll-A-Doors are available in an extensive range of standard Colorbond® colours including special Zincalume® coated finishes.

Zincalume® coated finish can be polyurethaned on site for even wider colour selection.

Maintenance

No greasing of the door guides is required, and the axle, hubs and all other working components have either been manufactured with self-lubricating materials or greased at the factory.

To reduce operational and replacement costs, curtains are easily repaired.

Options

B&D provide tapered curtains to suit floors with a slope across the opening

Optional electric and remote operation are available.

Ventilated Curtains

Where ventilation is required the doors may be perforated to allow light penetration or up to 10% airflow. This offeres you all the security you may need plus airflow.

High Wind Rated Roller Door

The B&D Roll-A-Door® S2 roller door been independently certified for use in all cyclone-affected regions throughout Australia

Our wind-locking technology incorporates a unique clip design  fitted to the edge of every flat on our high wind rolling doors. When exposed to high wind situations, this clip design ensures the door is held captive in the door track, it reduces the risk of both blow-in and blow-out wind forces, and provides added protection against forced entry
